Description
Mini Z-Wave™ switch module for home automation — Shelly. See below for the features and application conditions of this product.
Product information and features
FEATURES:
Latest Z-Wave technology (800 Series)
Z-Wave frequency band: 868.4 MHz (CEPT countries)
Automatic setup with SmartStart
Dry contact (potential-free) supporting up to 8A at 230V AC and 5A at 30V DC
Extremely low power consumption: < 0.3 W
Authenticated to the highest security level (S2)
Supports over-the-air (OTA) firmware updates
Works with certified Z-Wave gateways and over 4000 Z-Wave devices
SPECIFICATIONS
Power supply: 110-230V AC 50/60Hz
Power consumption: < 0.3 W
Contact:
· Potential-free: Yes (dry contact)
· Maximum AC switching voltage/current: 240V / 8 A
· Maximum AC switching power: 2000 W
· Maximum DC switching voltage/current: 30V / 5 A
CPU: Z-Wave™ S800 (System-in-package)
Z-Wave communication:
· Frequencies: Sub-G (from 868.4 to 920.9 MHz)
· Z-Wave™ repeater: Yes
· Range: Up to 40m in indoor spaces (depends on local conditions)
Overheating protection: Yes
Conductor cross-section: 0.5 to 1.5 mm² (20 to 16 AWG)
Enclosure material: Plastic
Operating temperature: -20°C to 40°C
Humidity: 30% to 70% RH
Color: Blue
Weight: 19 g
Size (H x W x D): 29x35x16 mm
