DIN rail module with 4 relays for home automation
Dispatch: Within 2 business days.
Once your order has been processed, you will receive a tracking number by email.
Description
DIN rail module with 4 relays for home automation. See below for the features and conditions of application of this product.
Product information and features
Description
Professional DIN rail module with 4 relays controllable via WiFi, Bluetooth, LAN, or directly using external buttons/switches.
It is a suitable device for home automation (domotics), offices, stores, industrial facilities, and other locations where remote control and energy management are important aspects.
WiFi/LAN connectivity uses HTTP/UDP protocols, allowing control via a smartphone, PC, home automation system, or any other device that supports these protocols. With an Internet connection, you can remotely control and monitor your Shelly® Pro 4PM from anywhere. Like many other Shelly® devices, this module is also compatible with the features supported by Amazon Echo and Google Home.
Used by those looking to automate lights, appliances, heating/cooling systems, and energy savings.
Specifications
| Power supply: | 110-240V; 50/60Hz AC |
| No. of channels: | 4 |
| Maximum current per channel: | 16A |
| Total maximum current: | 40 A |
| Power consumption: | < 4 W |
| Operating temperature: | from 0°C to 40°C |
| Smart On/Off: | Yes |
| Local and remote control: | Yes |
| Weekly schedule: | Yes |
| Sunrise / sunset: | Yes |
| Connectivity |
Wi-Fi: YES Bluetooth - YES LAN (Ethernet) - YES Radio protocol: WiFi 802.11 b/g/n Radio signal power: 1mW Frequency: 2412-2472 МHz; (Max. 2483.5 MHz) Operating range: up to 50m outdoors and up to 30m indoors |
| HTTP/HTTPS webhooks: | Yes |
| Scripting: | Yes |
| MQTT: | Yes |
| CoAP: | No |
| URL actions: | 20 |
| Scheduling: | 50 |
| CPU: | ESP32 |
| Flash: | 8MB |
| Protections: |
Overheating Overload Overvoltage Flame retardant material |
| Compliant with EU standards: | RED 2014/53/EU; LVD 2014/35/EU; EMC 2014/30/EU; RoHS2 2011/65/EU; |
| Mounting: | DIN rail |
| Dimensions: | 57.5 x 53.4 x 90 mm |
