DIN rail module with 1 relay and energy metering for Z-Wave™ automation

Ref.: 095-3209 MAUSER
In stock
€89,54 VAT included

Dispatch: Within 2 business days.

Once your order has been processed, you will receive a tracking number by email.

✓ Secure payment
✓ Fast shipping
✓ Customer support

Description

DIN rail module with 1 relay and energy measurement for Z-Wave™ automation. See below for the features and conditions of application of this product.

Product information and features

Description

Professional 1-channel Z-Wave® smart switch, with 16A contact and energy measurement; for mounting on a DIN rail (inside an electrical panel).

Suitable for the smart automation of homes and remotely controlled electrical installations.

Used by those looking to automate lights, appliances, underfloor heating and monitor light/electricity.

Specifications

Power supply 110-240V AC, 50/60 Hz
Own consumption < 0.3 W
Contact Maximum AC switching voltage/current: 240V / 16 A
Maximum DC switching voltage/current: not specified
Potential-free: No ("wet" contact)
Protection against overheating
overload
overvoltage
Power measurement Yes
Z-Wave communication Frequencies: Sub-G (from 868.4 to 920.9 MHz)
CPU: Z-Wave S800
Z-Wave™ repeater: Yes
Range: Up to 40m in indoor spaces (depends on local conditions)
Mounting DIN rail
Conductor cross-section Green connector: 0.5 to 2.5 mm (20 to 14 AWG)
White connectors: 0.5 to 1.5 mm (20 to 16 AWG)
Dimensions and materials Enclosure material: Plastic
Color: Red
Ambient temperature: -20°C to 40°C
Humidity: 30 % to 70 % RH
Maximum altitude: 2000 m
Weight: 60 g
Size (H x W x D): 94x19x69 mm
